250 °C
Maximum temperature
400 t
Maximum press force
MEYER Maschine: AHV
Available in different versions.
The AHV series is available in various designs and sizes: from models for small formats with 850 x 850 mm and a press force of 80 tons to large format machines with a working area of 3000 x 1600 mm and 400 tons of press force. This allows you to select the optimum machine for your individual requirements
Technical data
Machine
AHV
Fusing width (mm)
#
#
#
Dimensions L x W x H (mm)
#
#
#
Pressure (N/cm2)
#
#
#
Speed (m/min)
#
Features
Optional
All information summarized for you
Sign up and you will receive all relevant information about our laminating machines in a brochure.
Versions
You can find our AHV in various designs.
AHV 8585
Our hydraulic stamping and punching press with winding technology is specially designed for the “roll to roll” process. It enables efficient and precise stamping and punching directly from the roll.
- Application: stamping and punching from roll to roll
- Press area: 850x850mm
- Temperature: max. 250°C
- Material feed: discharging unit
- Press force: 80 tons
- Upper mold attached to upper heating plate via T-slots, punching plate inserted on lower table
AHV 2224
Our hydraulic embossing press with winding technology is optimized for the “roll to roll” process. It offers an efficient solution for precise stamping directly from the roll.
- Application: stamping from roll to roll and panels
- Press area: 2200x2400mm
- Temperature: max. 250°C
- Heating system divided into 20 zones, top and bottom
- Material feed: conveyor belt with feed device
- Press force: 120 tons
- Mold assembled on loading tray
AHV 3016
Our hydraulic hot forming stamping and punching press is equipped with a tool holder for large molding tools and an integrated punching function. The electrically heated press plates ensure even heat distribution and precise results.
- Application: Hot stamping and molding
- Press area: 3000x1600mm
- Temperature: max. 250°C
- Heating system divided into 12 zones, top and bottom
- Material feed: Blank feed
- Press force: 400 tons
- Mold assembled on top and bottom of heating plate
