MEYER machine: RPS-E2
Special feature: SIEMENS comfort controls
The advanced SIEMENS comfort controls of the latest generation offer you user-friendly operation via a large 7-inch touchscreen. The Ethernet and Profinet interfaces ensure seamless integration into your network.
Features
Optional
Technical data
Machine
RPS-E2
Fusing width (mm)
1.000
1.400
1.800
Dimensions L x W x H (mm)
4,105 x 1,580 x 1,250
4,105 x 1,980 x 1,250
4,105 x 2,380 x 1,250
Pressure (N/cm2)
50
35
18
Heating power (kW)
18,2
23,4
31,2
Connected load approx. (kW)
19
24,5
32,2
Pressure (N/cm2)
1.200
1.400
1.600
Speed (m/min)
1 to 12
control zones
2
Max. Temperature (°C)
200
Heating zone length (mm)
1.275
Voltage (Volt)
400
1,275 mm
Heating zone length
8.000
Parts per shift
2
Separate control zones
